Note:installed by crimp tool YYT-1
|
Insulated square：0.5～1.5mm2(AWG22～16) Max. cunrrent：lmax=19A
|
Item No
|
Dimension |
| PVC材質 |
尼龍材質 |
Fφ |
L |
H |
Dφ |
|
|
2.3 |
20.0 |
11.0 |
4.0 |
|
|
3.0 |
21.0 |
11.0 |
4.0 |
| DBF 1.25-14 |
DBF 1.25-14N |
3.0 |
24.0 |
11.0 |
4.0 |
| DBF 1.25-18 |
DBF 1.25-18N |
2.2 |
28.0 |
11.0 |
4.0 |
Insulated square：1.5～2.5mm2(AWG16～14) Max. cunrrent：lmax=27A
|
Item No
|
Dimension |
| PVC材質 |
尼龍材質 |
Fφ |
L |
H |
Dφ |
| DBF2-10 |
DBF2-10N |
2.4 |
19.0 |
11.0 |
4.5 |
| DBF2-14 |
DBF2-14N |
2.4 |
24.0 |
11.0 |
4.5 |
| DBF2-18 |
DBF2-18N |
2.4 |
28.0 |
11.0 |
4.5 |
Insulated square：4～6mm2(AWG12～10) Max. cunrrent：lmax=48A
|
Item No
|
Dimension |
| PVC材質 |
尼龍材質 |
Fφ |
L |
H |
Dφ |
| DBF5.5-10 |
DBF5.5-10N |
2.8 |
22.5 |
13.5 |
6.4 |
| DBF5.5-14 |
DBF5.5-14N |
4.5 |
26.5 |
13.5 |
6.4 |
| DBF5.5-18 |
DBF5.5-18N |
4.5 |
30.5 |
13.5 |
6.4 |
