Use note: installed by tool YYT-1
|
Insulation square：0.5～1.5mm2(AWG22～16)Max current：Imax＝19A
| Item No. |
DIMENSION
|
color |
|
America
Bolt no.
|
Dia. of bolt |
B |
L |
F |
H |
D Φ
|
| D2 |
mm |
mm |
mm |
mm |
mm |
| YF1.25-3N |
#4 |
3.2mm |
5.7 |
22 |
6.5 |
11.0 |
4.0 |
Red |
| YFS1.25-3.5N |
#6 |
3.7mm |
5.7 |
22 |
6.5 |
| YFL1.25-3.5N |
#6 |
3.7mm |
6.4 |
22 |
6.5 |
| YFS1.25-4N |
#8 |
4.3mm |
6.4 |
22 |
6.5 |
| YFM1.25-4N |
#8 |
4.3mm |
7.2 |
22 |
6.5 |
| YFL1.25-4N |
#8 |
4.3mm |
8.1 |
22 |
6.5 |
| YFS1.25-5N |
#10 |
5.3mm |
8.1 |
22 |
6.5 |
| YFL1.25-5N |
#10 |
5.3mm |
9.5 |
22 |
6.5 |
| YFS1.25-6N |
1/4 |
6.4mm |
9.5 |
22 |
6.5 |
| YFL1.25-6N |
1/4 |
6.4mm |
12.0 |
28 |
11.0 |
Insulation square：1.5～2.5mm2(AWG16～14)Max current：lmax＝27A
| Item No. |
DIMENSION
|
color |
|
America
bolt no.
|
Dia. of bolt |
B |
L |
F |
H |
D Φ
|
| D2 |
mm |
mm |
mm |
mm |
mm |
| YF2-3N |
#4 |
3.2mm |
5.7 |
22 |
6.5 |
11.0 |
4.5 |
Blue |
| YFS2-3.5N |
#6 |
3.7mm |
5.7 |
22 |
6.5 |
| YFL2-3.5N |
#6 |
3.7mm |
6.0 |
22 |
6.5 |
| YFS2-4N |
#8 |
4.3mm |
6.4 |
22 |
6.5 |
| YFM2-4N |
#8 |
4.3mm |
7.2 |
22 |
6.5 |
| YFL2-4N |
#8 |
4.3mm |
7.9 |
22 |
6.5 |
| YFS2-5N |
#10 |
5.3mm |
7.9 |
22 |
6.5 |
| YFL2-5N |
#10 |
5.3mm |
9.3 |
22 |
6.5 |
| YFS2-6N |
1/4 |
6.4mm |
9.3 |
22 |
6.5 |
| YFL2-6N |
1/4 |
6.4mm |
12.0 |
28 |
11.0 |
Insulation square：4～6mm2(AWG12～10)Max current：lmax=37A
| Item No. |
DIMENSION
|
color |
|
America
bolt no.
|
Dia. of bolt |
B |
L |
F |
H |
D Φ
|
| D2 |
mm |
mm |
mm |
mm |
mm |
| YF3.5-3N |
#4 |
3.2mm |
5.7 |
25.7 |
7.0 |
13.4 |
6.4 |
Yellow |
| YF3.5-4N |
#8 |
4.3mm |
8 |
25.7 |
7.0 |
| YF3.5-5N |
#10 |
5.3mm |
8 |
25.7 |
7.0 |
| YF3.5-6N |
1/4 |
6.5mm |
12 |
28.7 |
7.0 |
Insulation square：4～6mm2(AWG12～10)Max current：lmax=48A
| Item No. |
DIMENSION
|
color |
|
America
bolt no.
|
Dia. of bolt |
B |
L |
F |
H |
D Φ
|
| D2 |
mm |
mm |
mm |
mm |
mm |
| YFS5.5-3.5N |
#6 |
3.7mm |
7.2 |
24.4 |
7.5 |
13.4 |
6.4 |
Yellow |
| YF5.5-3.5N |
#6 |
3.7mm |
8.3 |
25.5 |
7.0 |
| YFS5.5-4N |
#8 |
4.3mm |
8.3 |
25.5 |
7.0 |
| YFL5.5-4N |
#8 |
4.3mm |
9.0 |
25.5 |
7.0 |
| YF5.5-5N |
#10 |
5.3mm |
9.0 |
25.5 |
7.0 |
| YFS5.5-6N |
1/4 |
6.5mm |
9.0 |
25.5 |
7.0 |
| YFL5.5-6N |
1/4 |
6.5mm |
12.0 |
31.5 |
12.0 |
| YF5.5-8N |
5/16 |
8.4mm |
14.0 |
30.5 |
10.5 |
