Material:copper insulated part:nylon  Note:installed by crimp tool YYT-1



Insulated square：0.5～1.5mm2(AWG22～16) Max. cunrrent：lmax＝10A

Item No.	NEMA TAB T×W	DIMENSION					Color
		W	F	E	dφ	L
PN1.25-110A	0.8×2.8	2.8	6.5	5.0	1.7	19.5	Red
PN1.25-187A	0.8×4.8	4.8	6.5	5.0	1.7	20
PN1.25-250A	0.8×6.35	6.35	8.0	5.0	1.7	22

Insulated square：1.5～2.5mm2(AWG16～14) Max. cunrrent：lmax＝15A

Item No.	NEMA TAB T×W	DIMENSION					Color
		W	F	E	dφ	L
PN2-187A	0.8×4.8	6.35	8.0	5.0	2.3	21	Blue
PN2-250A	0.8×6.35	6.35	8.0	5.0	2.3	22

Insulated square：4～6mm2(AWG12～10) Max. cunrrent：lmax＝24A

Item No.	NEMA TAB T×W	DIMENSION					Color
		W	F	E	dφ	L
PN5.5-250A	0.8×6.35	6.35	8.0	6.0	3.4	25.5	Yellow









RCCN  PNB Nylon Insulated Male Lug







Material:copper insulated part:nylon  Note:installed by crimp tool YYT-1



Insulated square：0.5～1.5mm2(AWG22～16) Max. cunrrent：lmax＝10A

Item No.	NEMA TAB T×W	DIMENSION					Color
		W	F	E	dφ	L
PN 1.25-250B	0.8×6.35	6.4	9.0	5.0	1.7	24	Red

Insulated square：1.5～2.5mm2(AWG16～14) Max. cunrrent：lmax＝15A

Item No.	NEMA TAB T×W	DIMENSION					Color
		W	F	E	dφ	L
PN 2-250B	0.8×6.35	6.4	9.0	5.0	2.3	24	Blue

Insulated square：4～6mm2(AWG12～10) Max. cunrrent：lmax＝24A

Item No.	NEMA TAB T×W	DIMENSION					Color
		W	F	E	dφ	L
PN5.5-250B	0.8×6.35	6.4	9.0	6.0	3.4	25.0	Yellow
